2/2 - G 1/8 PORTED VALVE QN = 350 L/MIN COMPRESSED AIR CONNECTION OUTPUT G 1/8 PIPE CONNECTION VERSION POPPET VALVE ACTIVATION MECHANICAL SWITCHING PRINCIPAL 2/2 NOMINAL FLOW QN 350 L/MIN WORKING PRESSURE MIN./MAX. 0 ... 10 BAR AMBIENT TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM COMPRESSED AIR MAX. PARTICLE SIZE 5 ?M OIL CONTENT OF COMPRESSED AIR 0 ... 5 MG/M? 3/2 - M5 PORTED VALVE QN PORTS 1 TO 2 = 190 L/MIN QN PORTS 2 TO 3= 150 L/MIN COMPRESSED AIR CONNECTION OUTPUT M5 PIPE CONNECTION VERSION POPPET VALVE ACTIVATION MECHANICAL SWITCHING PRINCIPAL 3/2 WORKING PRESSURE MIN./MAX. 0 ... 10 BAR AMBIENT TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM COMPRESSED AIR MAX. PARTICLE SIZE 5 ?M OIL CONTENT OF COMPRESSED AIR 0 ... 5 MG/M? 3/2 - G 1/8 PORTED VALVE QN PORTS 1 TO 2 = 250 L/MIN QN PORTS 2 TO 3= 150 L/MIN COMPRESSED AIR CONNECTION OUTPUT G 1/8 PIPE CONNECTION VERSION POPPET VALVE ACTIVATION MECHANICAL SWITCHING PRINCIPAL 3/2 WORKING PRESSURE MIN./MAX. 0 ... 10 BAR AMBIENT TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM COMPRESSED AIR MAX. PARTICLE SIZE 5 ?M OIL CONTENT OF COMPRESSED AIR 0 ... 5 MG/M? 3/2 - G 1/4 PORTED VALVE QN = 550 L/MIN COMPRESSED AIR CONNECTION OUTPUT G 1/4 PIPE CONNECTION VERSION POPPET VALVE ACTIVATION MECHANICAL SWITCHING PRINCIPAL 3/2 NOMINAL FLOW QN 550 L/MIN WORKING PRESSURE MIN./MAX. 0 ... 10 BAR AMBIENT TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM TEMPERATURE MIN./MAX. -30 ... 80 ?C MEDIUM COMPRESSED AIR MAX. PARTICLE SIZE 5 ?M OIL CONTENT OF COMPRESSED AIR 0 ... 5 MG/M? NOT FINDING WHAT YOU NEED? SEND US AN E-MAIL: SALES@THEPNEUMATICSTORE.COM
