THE AVENTICS SERIES QR1 COMPRESSED AIR FITTINGS ALLOW QUICK INSTALLATION AND EASY RECONFIGURATION OF PNEUMATIC SYSTEMS HAVING INCH TUBING/NPT THREADS AND METRIC TUBING/ISO-G(BSPP) THREADS. THE USER-FRIENDLY OVAL RELEASE RINGS ALLOW THE USER TO COMFORTABLY AND QUICKLY RELEASE THE TUBING FROM THE PUSH-LOCK CONNECTION BY PROVIDING MORE SURFACE AREA, UNLIKE TRADITIONAL ROUND RELEASE RINGS. QR1 FITTINGS COME IN STANDARD AND MINI SIZES, PLUS FUNCTION FITTINGS SUCH AS BALL VALVES, CHECK VALVES, FLOW CONTROLS, ETC. THEY FEATURE PREMIUM MATERIALS SUCH AS NICKEL-PLATED BRASS THREADS, AND A STAINLESS STEEL INTERNAL LOCKING MECHANISM.

SPECIFICATIONS

• WORKING PRESSURE VACUUM, -14 TO 145 PSI
• TEMPERATURE RANGE 32 ?F TO +140 ?F

FEATURES

• OVAL RELEASE RING FOR EASY REMOVAL OF TUBING
• LIGHT WEIGHT, SPACE-SAVING, POLYMER DESIGN, INHERIT CORROSION RESISTANCE
• NICKEL-PLATED BRASS THREADS
• STAINLESS STEEL TUBE LOCKING MECHANISM
• THREAD SEALANT ON NPT THREADS, FACE SEAL ON ISO-G THREADS
• OPTIMUM SEALING WITH CAPTIVE O-RING
• STANDARD SERIES FOR 10-32UNF TO 1/8" NPT(M3 TO G1/8) AND 1/8" TO 1/4" TUBING (3 TO 6MM)
• FUNCTION FITTINGS FOR 1/8" TO 1/2" NPT (G1/8 TO G1/2) AND 5/32" TO 1/2" TUBING (3MM TO 12MM)
