Item # 32-9090M12S-0
MODULAR SOLUTIONS FOOT & CASTER CONNECTING PLATE
90MM X 90MM, M12 HOLE, SOLID ALUMINUM
Click image to enlarge
Item # 32-9090M12S-0
MODULAR SOLUTIONS FOOT & CASTER CONNECTING PLATE
90MM X 90MM, M12 HOLE, SOLID ALUMINUM
- UM : EA
MODULAR SOLUTIONS FOOT & CASTER CONNECTING PLATE-90MM X 90MM, M12 HOLE, SOLID ALUMINUM
- MOUNTING PLATE 90 X 90
- M12 THREADED THRU HOLE
- METALIC IN COLOR
- MATERIAL: SOLID ALUMINUM
TECHNICAL
- WEIGHT: 0.05 LBS. / 0.02 KG.
- M12 X 1.75 THRU HOLE
- M8 COUNTERSUNK THRU HOLES
INFO
- COMMONLY USE TO MOUNT CASTERS AND STEM FEET
- NO MOUNTING HARDWARE
NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM
Specifications
| PLATE SIZE | 90 X 90 |
| THREAD SIZE | M12 |
| PLATE TYPE | MACHINED ALUMINUM PLATE |
Documents
×
