Item # 92320

NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI

  • $159.68 / EA
  • Manufacturer: NUMATICS
  • UM: EA

NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM

92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI
92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI
Click image to enlarge
92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI
92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI

Specifications

PORT SIZE 1/8"
PORT TYPE NPT
CONTROL FUNCTION SINGLE AIR PILOT
VALVE FUNCTION 4 WAY 3 POSITION - (5/2) SPRING RETURN
VOLTAGE 24 VDC
WIRING DIN CONNECTOR
SPECIAL OPTION PORT 2 PLUG

Item # 92320

NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI

  • $159.68 / EA
    • IF OUT OF STOCK, CONTACT FOR ETA
    • Log in to see if custom discounts apply

    Documents

    92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI
    92320 NUMATICS/AVENTICS AIR-PILOT VALVE L2 SERIES 4/3 1/8" NPT MAX PRESS 150PSI
